SK 2u 48 Port Patch Panel With FC SC ST Fiber Connectors , Fiber Termination Panel
Made of cold-rolling steel, static spreading-plastic, small dimension and exquisite and easy for operation.
The box are Rack Mounted, which is convenient to install and dismantle;
Features
Product Details:
|
Place of Origin: |
China |
|
Brand Name: |
TTI |
|
Certification: |
ISO, SGS, ROHS |
|
Model Number: |
OTB-RS-LC24 |
Payment & Shipping Terms:
|
Minimum Order Quantity: |
10 pcs |
|
Price: |
Negotiation |
|
Packaging Details: |
Box |
|
Delivery Time: |
2-3 days |
Detailed Product Description
|
Structure: |
19'' Rack Mounted |
Model: |
Fixed Type, Slidable Type |
|
Connector: |
SC LC FC ST |
Material: |
Cold Rolled Steel, AL |
|
Color: |
Black, White, Grey |
Port: |
48 Port |
|
Height: |
2U |
Thickness: |
0.8mm,1.0mm, 1.2mm |
48 Port 2U Fiber Optic Patch Panel with ST Fiber Optic Adapter
Description:
Made of cold-rolling steel, static spreading-plastic, small dimension and exquisite and easy for operation.
The box are Rack Mounted, which is convenient to install and dismantle;
The splice tray could be piled one upon another, flexible to turn;
The box is of unique structure, reasonable layout, and has adequate room for operation;
Adjustable clamp seal ring and reinforce configuration, which could adjust different sizes of cables flexibly to make sure the cables are clamp tightly;
The indoor type is of excellent seal performance, which could prevent water from entering effectively;
Feature:
Applicable in the straight through or branch connection of indoor cable
Available for the distribution and terminal connection of various kinds of optical fiber system
Max capacity cores from 12 to 96 with SC/LC/ST/FC connectors
Insertion loss: <0.3dB
Return loss: PC< 40 dB, UPC<50dB, APC< 60dB
Working temperature -25°C~+45°C
Application:
Cabinet, FTTH Network
Telecommunication, CATV
Meet need of signal distribution and management in passive optical network
Specification
Specification:
Fixed Type:
|
Type |
OTB-RF-1UA |
OTB-RF-2UA |
OTB-RF-1UB |
OTB-RF-1UB |
OTB-RF-1UC |
OTB-RF-2UC |
|
Size(mm) |
430*250*1U |
430*250*1U |
482*295*1U |
320*240*100 |
350*340*120 |
350*340*120 |
|
Max capacity(core) |
24 |
48 |
24 |
48 |
24 |
48 |
|
Weight(kg) |
2.6 |
3.8 |
3 |
4 |
3 |
5 |
Slidable Type:
|
Type |
OTB-RS-1UA |
OTB-RS-2UA |
OTB-RS-1UB |
OTB-RS-2UB |
OTB-RS-1U-3MPO |
OTB-RW-1U |
|
Size(mm) |
430*300*1U |
430*250*2U |
482*217*1U |
482*217*2U |
482*296*1U |
430*300*1U |
|
Max capacity(core) |
24 |
48 |
24 |
48 |
36 |
24 |
|
Weight(kg) |
3.5 |
4.0 |
3.5 |
4.0 |
3.0 |
4.7 |
