SK UPC Precision Ceramic Ferrule SC Fast Fiber Optic Connector for FTTH Drop Cable
No special assembling tool
Easy for assembling with mechanical splice and no polishing
Easy for learning technology by a simple assembling method (within 1 and half minutes)
Features
Product Details:
|
Place of Origin: |
China |
|
Brand Name: |
TTI |
|
Certification: |
ISO, SGS, ROHS |
|
Model Number: |
FSC-001 |
Payment & Shipping Terms:
|
Minimum Order Quantity: |
10 pcs |
|
Price: |
Negotiation |
|
Packaging Details: |
PE bag |
|
Delivery Time: |
2-3 days |
Detailed Product Description
|
Connector Type: |
SC |
Ferrule End-face: |
UPC |
|
Fiber Type: |
SM |
Cable Type: |
Simplex |
|
Cable OD: |
0.9/2.0/3.0mm |
Housing Color: |
Blue |
|
Insertion Loss: |
<0.3dB |
Return Loss: |
>50dB |
SC Fast Connector for FTTH Drop Cable with UPC Precision Ceramic Ferrule
Features:
No special assembling tool
Easy for assembling with mechanical splice and no polishing
Easy for learning technology by a simple assembling method (within 1 and half minutes)
Minimize the defect rate by features of removal and reusable
Application:
Telecommunication
networks
Patch panels
Distribution frames
Maintenance or emergency restoration of fiber networks
FTTH Outlets
Specification
Specification:
|
Item |
Parameter |
|
Cable |
3.1x2.0mm drop cable or 3.0/2.0/0.9mm cable |
|
Coating Diameter |
250μm |
|
Mode |
SM, MM |
|
Insertion Loss |
≤ 0.3dB |
|
Return Loss |
SM: ≥45dB; MM: ≥35dB |
|
Reusable Times |
>10 times |
|
Tensile Strength |
>50 N |
|
Temperature |
-40~+85°C |
FTTH Fast Connector Package:
The package will be packed according to standard export requirements, customer satisfication is our target.
Label printing : Customer logo or None brand are available
Inner packing: 10pcs/PE box
Outer packing: the carton will be packed with sack, well protect carton from dust and wet.
