SK MTRJ Duplex Fiber Optic Patch Cord OM3 Duplex Low Insertion Loss
Features
Product Details:
|
Place of Origin: |
China |
|
Brand Name: |
TTI |
|
Certification: |
ISO, SGS, ROHS |
|
Model Number: |
MTRJ-LC-OM3 |
Payment & Shipping Terms:
|
Minimum Order Quantity: |
20 pcs |
|
Price: |
Negotiation |
|
Packaging Details: |
PE bag |
|
Delivery Time: |
2-3 days |
Detailed Product Description
|
Connector Type: |
LC-MTRJ |
Ferrule End-face: |
UPC |
|
Fiber Type: |
OM3/OM4 |
Cable Type: |
Duplex |
|
Cable OD: |
2.0mm |
Cable Jacket: |
PVC/LSZH/OFNR/OFNP |
|
Cable Length: |
1M, 2M, 3M Or Customized |
Cable Color: |
Aqua Color Or Customized |
MTRJ Duplex Fiber Optic Patch Cord OM3
Duplex Low Insertion Loss
Description:
The LC connectors used in fiber optic patch cords are designed to LC standards with high quality ceramic ferrules and non-optical disconnect performance.
They are fully compatible with existing LC hardware.In addition to basic testing, some mechanical and environmental tests per IEC or Telcordia are also performed periodically to guarantee the best quality.
There are three kinds of polished fiber end-face: PC, UPC and APC .we employ advanced technique and equipment to manufacture so as to ensure the high quality of mass production.
Features:
Good exchangeability
Good Durability
High temperature stability
Low insertion loss and High back reflection loss
Application:
Local Area Networks
Active device termination
Telecommunication networks
Data processing networks
Test equipment
Specification
Specification:
|
Specification |
Unit |
FC, SC, LC/Armored Cable |
ST, MU |
MT-RJ, MPO |
D4 |
||||||||
|
SM |
MM |
SM |
MM |
SM |
MM |
SM |
|||||||
|
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
PC |
UPC |
PC |
PC |
APC |
||
|
Insertion loss |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.3 |
|
Return loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
≥45 |
≥50 |
≥30 |
≥45 |
≥50 |
≥35 |
≥50 |
≥60 |
|
Wavelength |
nm |
850,1310 |
850,1310 |
850,1310 |
850,1310 |
||||||||
|
Interchangeability |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.2 |
||||||||
|
Vibration |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.2 |
||||||||
|
Operating temperature |
°C |
-40~75 |
-40~75 |
-40~75 |
-40~75 |
||||||||
|
Storage temperature |
°C |
-45~85 |
-45~85 |
-45~85 |
-45~85 |
||||||||
|
Cable diameter |
mm |
φ3.0,φ2.0,φ0.9 |
φ3.0,φ2.0,φ0.9 |
φ3.0,φ2.0,φ0.9 |
φ3.0,φ2.0,φ0.9 |
||||||||
Order Information:
|
LC/UPC-MTRJ/UPC-OM3(50)-DX-2.0mm-1M |
|
||||||||||||||
|
LC |
/ |
UPC |
— |
MTRJ |
/ |
UPC |
/ |
OM3 |
— |
DX |
/ |
2.0 |
— |
1M |
|
|
1 |
|
2 |
|
3 |
|
2 |
|
4 |
|
5 |
|
6 |
|
7 |
|
|
|
|||||||||||||||
|
1 |
Connector#1: LC, SC, FC, ST, DIN, D4, MU, MTRJ, etc. |
||||||||||||||
|
2 |
Lapping Way: UPC&APC (For MTRJ, F=Female, M=Male) |
||||||||||||||
|
3 |
Connector#2: LC,SC,FC,ST,DIN,D4,MU,MTRJ,Pigtail,etc. |
||||||||||||||
|
4 |
Cable Type: SM(9/125μm) ,MM(50/125μm & 62.5/125μm), OM3, OM4 |
||||||||||||||
|
5 |
Fiber Number: SX(Simplex) or DX(Duplex), 2/4/6/8 core... |
||||||||||||||
|
6 |
Cable Diameter: 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc. |
||||||||||||||
|
7 |
Cable Length: 1m, 2M...(Length in meter) |
||||||||||||||
