SK PVC LSZH LC Pigtail Fiber Optic 1~ 144 core for Data processing networks

  1. 1~ 144 core available
  2. 0.9, 2.0, 3.0 fan-out available
  3. Easy to use, easy to install and maintain
  4. Environmentally stable

Features

Detailed Product Description

PVC LSZH LC Fiber Optic Pigtail 1~ 144 core for Data processing networks

Quick details

  1. 1~ 144 core available
  2. 0.9, 2.0, 3.0 fan-out available
  3. Easy to use, easy to install and maintain
  4. Environmentally stable
  5. Fan-out available
  6. Cable out jacket: PVC, LSZH, OFNR, OFNP… available

Features:

Low insertion loss and back reflection loss

Good exchangeability

Good Durability

High temperature stability

Applications:

Premise installations

Optical access network

Data processing networks

FTTH, LAN, CATV, Test equipment

Specification

Specification:

Mode

SM

MM

Polish

UPC

APC

PC

Insertion Loss

Typical ≤0.2dB

Maximum ≤0.3dB

≤0.25dB

Return Loss

≥50dB

≥65dB

≥35dB

Interchangeability

≤0.2dB

Repeatability

≤0.1dB

Durability

≤0.2dB (1000 times mating)

Tensile Strengh

> 10kg

Temperature

≤0.2dB (-40+85 sustain 100 hours)

Humidity

≤0.2dB  (+25+65 93 R.H.100 hours)

Ordering Information

Boot (cable)

Size

Boot

Color

Fiber Type

Cable number

Application

Length

0.9mm

Black

9/125μm (SM)

Simplex

PC

Customized

2.0mm

Green

50/125μm (MM)

Duplex

APC



3.0mm

Red

62.5/125μm (MM)

Fan-out (4f)











Fan-out (6f)











Fan-out (8f)











Fan-out (12f)
