SK SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable

Fiber Optic Patch Cables are available in both multimode and single mode cable types, in Simplex and Duplex version.
Fiber optic patch cord is suited for equipment jumper cable, cross connects, and work area connections.

Download PDF Submit your Inquiry

Features

Product Details:
Place of Origin: China
Brand Name: TTI/OEM/ODM
Certification: ISO, SGS, ROHS
Model Number: LC-ST-OM3
Payment & Shipping Terms:
Minimum Order Quantity: 20 pcs
Price: Negotiation
Packaging Details: PE bag/Cartons
Delivery Time: 2-3 days
Detailed Product Description
Connector Type: LC-ST Fiber Type: OM3/OM4
Cable Type: Duplex Cable OD: 2.0mm
Cable Jacket: PVC/LSZH/OFNP Cable Color: Aqua, Purple, Violet Or Customized
SC - LC Fiber Optic Patch Cord , Violet / Purple OM3 50/125 Cable
Description:
Fiber Optic Patch Cables are available in both multimode and single mode cable types, in Simplex and Duplex version.
Fiber optic patch cord is suited for equipment jumper cable, cross connects, and work area connections.
All fiber optic patch cords are manufactured with telecom class and polished A, and 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards.
Features:
Good durability
Good exchangeability
High temperature stability
Price Competitive
Factory-terminated and Tested
Application:
Local Ring Network
Optical Fiber Sensor
Telecom Network
Optical Fiber Test Equipment
FTTH,LAN,PON & Optical CATV

Specification

Specification:

Mode	SM			MM
Polishing	PC	APC	UPC	PC	UPC
Insertion Loss	≤0.3dB	UPC≤0.3dB	APC≤0.3dB	APC≤0.3dB	APC≤0.3dB
Return Loss	PC≥52dB	APC≥65dB	UPC≥55dB	PC≥35dB	UPC≥35dB
Exchangeability	≤0.2dB
Salt Spray	≤0.2dB
Vibration	(550Hz 1.5mm) ≤0.1dB
Apex Offset	0μm≤≤50μm
Radius of Curvature	7mm≤≤25mm
Humidity	(+25+65 93 R.H.100 hours) ≤0.2db
Cable Type	TypeSimplex, Duplex, Fan-Out
Connector Type	LC,SC,FC,ST, MU, MPO, MTRJ,DIN, SMA, FDDI
